DISARMO UNIVERSALE
Environmental-friendly, ready for use, form-release agent, developed by WINKLER Research & Development Laboratories.
- Use Fields DISARMO UNIVERSALE is a product intended for the release of prestressed and non concrete, subject to natural, accelerated or steam curing for wooden, metal, polystyrene, rubber and polyurethane formworks. It does not allow any barrier effect, which allows painting, plastering, or any other covering without subsequent detachments.
- Application The product is ready for use and can be applied using a roller, hand brush or an airless gun. In case of new formworks, particularly absorbent or restored due to rust, double application is recommended. Wait for the evaporation of the water and the appearance of the oily surface before the installation.
- Consumption 20-25 g/m2 About 30 g/m2 with double applicazione
- Surface Preparation Carefully clean the base in order to remove: dust, oil, grease and any foreign bodies or substances impeding adhesion. Apply on a dry surface.
- Useful Advices Before pouring, make sure that the product is completely dry. We recommend applying at temperatures between +5°C and +35°C
- Packaging 5-20 litre jerrycans.
- Storage If the product is stored in its unopened original packaging in a dry and protected place, shelf-life is 12 months. Not frost-proof. Store at temperatures between +5°C and +35°C.
- Technical data sheet
Warning: count(): Parameter must be an array or an object that implements Countable in /home/customer/www/winklerchimica.com/public_html/wp-content/themes/winkler-chimica/inc/loop-portfolio_carousel.php on line 75
TECHNOASFALT
TECHNOASFALT is a THIRD GENERATION cold bituminous conglomerate workable at ambient temperature, made with SBS e SBR Modified Bitumen coming from the end of life’s tyres (PFU) fluidized with selected vegetable oils. It is a selected mixture (sands, first class basaltic granules). The binder is made of cold modified bitumen with elastomers, eco- friendly vegetable
- Application Practical to use, it is advisable to clean the application area before, then lay TECHNOASFALT. The product does not require any priming layers not even on damp and wet areas. It can be applied manually and/or with vibratory finishing machine, quickly eliminating the hidden danger due to the road paving asymmetry so to guarantee the users safety, even on wet substrates.
- Consumption Approximate consumption 22/23 kg for each sq.mt./cm of pressed thickness.
- Useful Advices Keep the bags sealed very well, if possible sheltered from atmospheric agents, without overlapping the pallets. A good handling of the packaging and the pallets allow the product to remain workable for a 24 month’s period from packing date. To facilitate the handling in particularly cold periods, it is advisable to store the bags at temperature close to +10°C. To facilitate the tempering and an easy application, open the bags completely before the use to air the product.
- Packaging 25 Kg bags (60 bags per pallet).
- Storage The product has 12 month’s stability if properly packed and stored in a cool dry place. Store at temperatures between +5°C and +35°C. No frost-proof. Pallets do not be stacked.
- Technical data sheet
WINDECK
Transparent protective product with low viscosity specifically made to waterproof balconies and terraces subjected to infiltrations. Its exclusive formulation, applied in single coating of approximately 900 micron (0.9 mm) thickness, guarantees the substratum waterproofness without changing the appearance of tiles. The product has proven resistant to frost-defrost cycles, to thermal shocks; it has excellent durability
- Application The product is ready to use, doesn’t require the use of a primer and can be applied on a dry support with teethed metallic spatula following by a passage with a spiked roller to eliminate possible trapped air bubbles. Apply the product is one coat to obtain a homogeneous thickness.The substrate treated with WINDECK is passable after 72 hours from the application with an average temperature of 20°C.
- Consumption 0,9 kg/m2 in one coat.
- Useful Advices Thoroughly clean the support in order to remove: dust, friable parts, alien or anti-adherent substances. Make sure that the surface is dry to avoid the formation white spots, bubbles and detachment problems.Apply WINDECK with temperature between +5°C e + 35°C. Do not add water and/or solvents. Protect during the first 48 hours from the application from water, rain and snow. Do not apply in the event of high humidity (>80%).
- Packaging 5-20 kg buckets
- Storage The product in its undamaged packaging can be store for 12 months. No frost-proof. Store at temperatures between +5°C e +35°C.
- Technical data sheet
WINGUM PRO TECK
WINGUM PRO TECK is an elastomeric, bitumen-based, thixotropic, liquid waterproofing membrane that is resistant to ponding water, and due to the new generation formulation by the WINKLER R&D Lab, it can be exposed without protection, to UV rays up to a maximum exposure of two years. WINGUM PRO TECK gained the important EC1 PLUS brand,
- Use Fields The product can be used for applications in concrete, fibre-cement, wood, natural stone, brickwork and bituminous facing supports in general. Also to waterproof foundations, service terraces and in the recovery of damaged bituminous facings. It is suitable as waterproofing layer before the application of floating floors and, thanks to the corrosion inhibitor contained within it, it can be used for waterproofing metal surfaces, even oxidizable, without the need for specific primers.
- Application The product is ready to use, mix manually with a spatula until getting a homogeneous appearance. It can be applied with a roller, brush, spatula or trowel.
- Consumption 1 - 1.2 kg/m2 in two or more coats, on vertical surfaces. 1.2-1.6 kg/m² in two or more coats, on horizontal sufaces. 1.6 – 1.8 kg² in two coats, with reinforcement WINTECHNO MAT.
- Surface Preparation Accurately clean the substrate area to eliminate: dust, crumbly, foreign or bonding-proof substances. Apply only on dry surfaces and supports. Check the substrate support area is not wet to avoid onset of air bubbles due to vapour pressure. A practical method to check hidden wet in the support to be treated could be to cover a square metre of the surface - better when exposed to the sun – with a polyethylene sheet of almost 2 tenths, fully sealing it at edges with double-bond tape. After 24–48 check the possible condensation water under it. On powdery floor foundation, in order to allow the adhesion, it is advised to use the preventive application of WINFIX CONCRETE, or you can use WINGUM PRO TECK as well, which has been previously diluted with 20% clean water (1.0L for 5kg bucket, 2L for 10kg bucket and 4L for 20kg bucket). Wait until the layer is dry (about 30 minutes at +20°C) and then apply the product again.
- Useful Advices Apply WINCUM PRO TECK at temperatures between +5°C and +35°C. WINGUM PRO TECK cannot perform its waterproofing functions if it does not dry completely at least once, therefore it must not be applied with bad weather, rainy weather and on frost surfaces or subject to night chill. Protect it during the first 24 hours from water, rain, snow. Do not apply in case of high night dampness. If WINGUM PRO TECK has to be applied on a bitumen-polymer membrane, make sure that it has undergone at least 180 days of oxidation. Better protection and durability characteristics against UV are reached by using the products of ECOSILVERALL, COVERAME, 2000 PLUS and 2000 PLUS REFLEX series, as protective coatings. Wait at least 48 hours after the last coat before applying other products. In case of backfill, we recommend to wait at least 3 days from the final coat application and protect the surface treated with WINGUM PRO TECK with a HDPE draining embossed membrane. The temperature, humidity and porosity of the substrate could influence the drying times of the product.
- Packaging 5-10-20 kg buckets.Boxes composed of 30 x 1kg pails.
- Storage The product in its undamaged packaging can be stored for 24 months. Please store it at temperatures between +5°C and +35°C. No frost-proof.
- Technical data sheet
- Certifications
WINGUM PRO TECK ANTIRADICE
WINGUM PRO TECK ANTIRADICE is a fibre-reinforced, elastomer-bituminous based waterproofing liquid membrane, designed and formulated by WINKLER R&D. It is root-proof and resistant to ponding water. Formulated with new generation raw materials, it can prevent the penetration of roots meeting the requirements of the UNI EN 13948 standard.
- Use Fields The product is used for protecting and waterproofing surfaces, including flat surfaces, such as concrete, fibre-cement, wood and brickwork which is intended to hold plants, seeds and roots. This includes planters and raised gardens. It can also be applied on bituminous membranes (both smooth or slated).
- Application The product is ready to use. Apply WINGUM PRO TECK ANTIRADICE by roller, paintbrush, spatula or trowel. As performances depend on possible superficial damages, in addition to support porosity, to achieve a homogenous and continuous layer, it is advised to apply two or more coats, by soaking/inserting the reinforcement WINTECHNO MAT, between the first and the second coat. Apply the second coat exclusively when the first one is fully dried.
- Consumption 2 - 2.5 kg/m2 in 2 or more coats, by inserting WINTECHNO MAT in between.
- Surface Preparation Accurately clean the support to eliminate: dust, crumbly parts, foreign or bonding-proof matters. Apply on dry surfaces and supports. Check foundation wet to avoid onset of bubbles due to vapour pressure. On powdery floor foundations, in order to allow the adhesion, it is advised the preventive application of WINFIX CONCRETE, or WINGUM PRO TECK ANTIRADICE as well, which has been previously diluted with 20% clean water (1.0L for 5kg bucket, 2L for 10kg bucket and 4L for 20kg bucket). Wait until the layer is dry (about 30 minutes at +20°C) and then apply the WINGUM PRO TECK ANTIRADICE.
- Useful Advices Do not add any additive. Do not use if the packaging is damaged. Do not add water. WINGUM PRO TECK ANTIRADICE cannot perform its waterproofing functions if it does not dry completely at least once, therefore it must not be applied with bad weather, rainy weather and on frost surfaces or subject to night chill. Protect it during the first 24 hours from water, rain, snow. Do not apply on wet surfaces.
- Packaging 5-20 kg buckets.
- Storage The product in its undamaged packaging can be stored for 24 months. Please store it at temperatures between +5°C and +35°C. No frost-proof.
- Technical data sheet
BC SEAL BAND
Self adhesive band based on butylic mastic covered with non-woven which allows the deformation of the product. The adhesive side is protected by peel off support.
- Use Fields sealing wall-to-floor joints on cementitious substrates, bricks, asbestos cement, metal or tiled flooring before applying liquid or cement waterproofing products from WINKLER range. The non-woven fabric covering adapts to the shape of the support, can be easily shaped to fit corners, drains, pipes etc. where can be used in combination with BC SEAL PAD.
- Application Remove the protection, put the band on the support avoiding the formation of air bubbles between the butyl and the support. For joints superimpose the products of at least 5 cm. For sealing substrates subject to significant expansion, it is recommended to provide a method of application of BC SEAL BAND, suitable to withstand such tensions. For example, in the case of overlapping between corrugated sheets, apply the two edges of the strip on the portions of the sheet to be connected, leaving the central part free, thus creating an "omega". Apply at temperatures between +5°C and +40°C.
- Surface Preparation Application surfaces must be clean, dry and free from dust, oils, foreign or non-stick substances. On powdery substrates it is advisable to favor the adhesion, a prior application of WINFIX CONCRETE.
- Useful Advices Prior the application it is advisable to restore any irregularities on the surface, glue any detached tiles and check for hidden humidity to avoid the formation of vapor tensions. Avoid use when rainy weather is imminent and on wet surfaces. Cover the product within 24 hours, after its application.
- Packaging 1 roll per box – 80mm x 10m
- Colours Non-woven: whiteButyl: grey
- Storage The product has 12 month’s stability from the production date if properly packed and not opened. Store in a ventilated room sheltered from dampness at temperatures between +5°C and +35°C.
- Stratigraphy BC SEAL BAND on wall-floor corner
- Technical data sheet
WINTECHNO MAT
Non-woven, polyester reinforcement mat for WINKLER range’s liquid waterproofing membranes. The product has the following features: Non-allergenic. Rot-proof. Resistant to atmospheric agents. Easy-fitting to every kind of surface.
- Use Fields WINTECHNO MAT is an ideal reinforcement for liquid waterproofs. Thanks to its flexibility it assures a great adaptation to the treated surfaces while for its extreme permeability it goes together well with the waterproofing liquid. Its versatility and the small thickness make WINTECHNO MAT an effective instrument even in case of existing floors, where fallowing height differences, particularly near doorsteps, is extremely binding. WINTECHNO MAT is a valid system to be used on large surfaces (>50sqm), tiled floors, gutters and on substrates subject to movements, to allow the liquid waterproofer to effectively absorb the tensions created by the substrate.
- Application For the application, always refer to the technical data sheets of the liquid membrane chosen for waterproofing.
- Packaging 1 X 200m2 roll.
- Technical data sheet
WINSEAL
WINSEAL is a mastic based on bitumen, chemical products, polymers and a non-chlorinated and non-toxic solvent.
- Use Fields Sealing of roofs, ponds, water mirrors and particular points, such as gutters, chimneys, ventilation ducts, lighting points, finishing of vertical and horizontal joints, repairs (emergency), protection against corrosion.
- Consumption Adhesion: 310ml/m² (about 400g/m²) As filling: 310ml (about 400g) for 10m (0.5x 0.5 cm curb) For thicknesses from 1.5 to 2 mm: 3.85ml/m² (approx. 5kg/m²)
- Surface Preparation Thoroughly clean the support to remove: dust, loose parts, foreign or non-stick substances
- Packaging (280 ml) cartridge – 25 cartridges per box.
- Storage Storage life is more than 3 years after the date of production in its original packaging in a dry, cool and frost-free environment. Store at temperatures between + 5°C and +35°C.
- Technical data sheet
WINLIVEL
Self-leveling cement-based premixed product, suitable for both indoor and outdoor applications, with special binders and selected mineral fillers, formulated byWINKLER R & D laboratories.
- Use Fields Product used for grinding floors with irregularities from 1 to 15 mm, screeds or existing floors. In just a few hours it develops a smooth and solid surface, suitable for overlapping ceramic, marble, terracotta, stoneware, parquet, resilient or liquid membranes of WINKLER range.
- Application Mix with clean water until the mixture is perfectly homogeneous and free of lumps. To favor the adhesion of the product on the support, it is recommended to apply WINLIVEL with a spatula, exerting a slight pressure. On still wet product, we recommend using a spiked roller, to eliminate any air bubbles.
- Consumption 2 kg / m² per mm of thickness.
- Surface Preparation Thoroughly clean the surfaces that must be free of salts, oils, greases, friable parts and foreign or anti-adherent substances. Wet absorbent substrates, before the application. Prior to applications on ceramic or low wettability coatings, apply WINGRIP EVO as an adhesion promoter.
- Useful Advices In case of wood, parquet and other coatings particularly sensitive to humidity, apply WINLIVEL with a thickness of ≥ 5mm, in addition it is always recommended to check, using a carbide hygrometer, that the residual humidity is equal to or less than 2%, before over application. We recommend to apply at temperatures between + 5 ° C and + 35 ° C. Protect from sun and wind during the first 24 hours, if necessary keep on moistening the surface even after application. Remove fresh mortar from the tools used for preparation and application, with running water. After hardening, cleaning only mechanically.
- Packaging 25 kg bags
- Storage The product, in its original, unbroken packaging, has a stability of 12 months. Store at temperatures between + 5 ° C and + 35 ° C.
- Technical data sheet
- Certifications
- Declaration of performance WINLIVEL DoP
WINLIVEL RAPID
Self-leveling, fast-curing, premixed product, for indoor and outdoor applications, also at high temperatures, with special binders and selected mineral fillers.
- Use Fields Product used for grinding floors with irregularities from 1 to 20 mm, screeds or existing floors. In just a few hours it develops a smooth and solid surface, suitable for overlapping ceramic, marble, terracotta, stoneware, parquet, resilient or liquid membranes of WINKLER range. WINLIVEL RAPID is used in all situations where rapid over-application and flooring set up is needed. WINLIVEL RAPID can also be applied at low temperatures (≥ 2 ° C).
- Application Mix with clean water until the mixture is perfectly homogeneous and free of lumps. To promote the adhesion of the product on the support, it is recommended to apply WINLIVEL RAPID with a spatula, exerting a slight pressure. On still wet product, we recommend using a spiked roller, to eliminate any air bubbles.
- Consumption 2kg/m2 per 1 mm thickness
- Surface Preparation Thoroughly clean the surfaces that must be free of salts, oils, greases, friable parts and foreign or anti-adherent substances. Soak absorbent substrates, before the application. Prior to applications on ceramic or low wettability coatings, apply WINGRIP EVO as an adhesion promoter
- Useful Advices In case of wood, parquet and other coatings particularly sensitive to humidity, apply WINLIVEL RAPID with a thickness of ≥ 5mm, in addition it is always recommended to check, using a carbide hygrometer, that the residual humidity is equal to or less than 2%, before over application. We recommend to apply at temperatures between + 5 ° C and + 35 ° C. Protect from sun and wind during the first 24 hours, if necessary keep on moistening the surface even after application. Remove fresh mortar from the tools used for preparation and application, with running water. After hardening, cleaning only mechanically.
- Packaging 25 kg bags
- Storage The product, in its original, unbroken packaging, has a stability of 12 months. Store at temperatures between + 5 ° C and + 35 ° C.
- Technical data sheet
- Certifications
- Declaration of performance WINLIVEL RAPID DoP
WINGUM PLUS H2O
Coloured waterproofing water-based liquid membrane based on modified resins. Ideal also for large surfaces. WINGUM PLUS H2O gained ICC-ES DoP, according to ASTM D 6083 regulation, MIAMI DADE COUNTY acknowledgment, and CRRC certification. It is also certified in AEU. It meets the ETAG 005 guide lines, about liquid products applied as waterproofing ones. WINGUM PLUS
- Use Fields Its particular formulation, allows high flexibility, the product is stable also at very low temperatures. It normally steps steady. WINGUM PLUS H2O is suitable where very good resistance to backwater is required, also on flat surfaces subject to stagnation. It has an excellent resistance to ageing and U.V. rays. Suitable for waterproofing of concrete supports, fibre-cement slabs, metal sheds also oxidizable, woods, ceramic tiles or natural stone floorings, brickworks, bitumen-polymer membranes (oxidized for a minimum of 180 days), XPS, EPS and polyurethane insulating panels.
- Application The product is ready to use and can be applied with short-bristle roller for solvent, brush, large paintbrush, steel plastering towel and airless gun. Apply at least two coats of the product to achieve homogenous thickness, ideal for waterproofing. In order to assure waterproofing function, on perimeter edges of the surface, apply the waterproofing adhesive band BC SEAL BAND.For waterproofing and sealing around roof penetrations such as drain, ventilation pipes, other roof penetrations or around plumbing pipes and drains, use BC SEAL PAD, self-adhesive butyl square pad.
- Consumption 1,2 - 1,4 kg/m2 in two coats.1,8 – 2,0 kg/m2 on concrete in two coats with reinforcement interposed.
- Surface Preparation On irregular supports, it is advisable making a previous application of WINFIX CONCRETE, in order to allow adhesion. For smoothing floors use WINLIVEL, self-leveling for irregularities from 1 to 15mm or WINLIVEL RAPID, quick-drying self-leveling for irregularities from 1 to 20 mm. To make a new screed, use WINPLAN 370, a quick-drying screed or WINPLAN PRO, a fast-drying and low water absorption screed.
- Useful Advices Apply WINGUM PLUS H2O at temperatures between +5°C and +35°C. protect it from water, rain and snow during the first 24 hours from its application. Do not apply if night dampness is imminent.
- Packaging 5-10-20 kg buckets.
- Colours White, grey, red, green.
- Storage The product in its undamaged packaging can be stored for 24 months. The products can be stored also at temperature between +5°C and +40°C. It is not frost-proof.
- Stratigraphy WINGUM PLUS H2O REFLEX on smooth bituminous membrane WINGUM PLUS H2O REFLEX on concrete WINGUM PLUS H2O REFLEX on existing flooring ONE and WINJOINT SYSTEM
- Technical data sheet
- Certifications
- Declaration of performance Declaration of Performance
ONE
One-component liquid pigmented waterproofing, formulated so as to give peculiar characteristics of impermeability, and long-lasting protection for treated substrates. Specially designed to be applied in extreme conditions: low and high temperatures (from 0 ° C to + 45 ° C), damp, very damp or wet substrates. The product remains stable to thermal shocks.
- Use Fields Cement-based screeds not completely seasoned (i.e: 7 days at 15°C), concrete substrates, tiled balconies with permanent problems of excess humidity, tiles, metal surfaces in general, wood, brick, fiber-cement, bituminous membranes, oxidized, both smooth and slated. The product, when fully cured, is resistant to wear by even intense pedestrian passage and, thanks to its mechanical resistance, on rigid substrates (concrete and tiles) makes it possible to place chairs and tables.Once applied, after a few hours it is completely rain-proof.
- Application Prepare the substrate to be treated as described in the paragraph "surface preparation". Before applying, quickly mix the product. The product is ready to use and does not require a primer. ONE is applied with a short-haired roller, flat brush, metal spatula and airless pump (LARIUS series ZEUS, DRAGON OR THOR) For further specifications, contact WINKLER technical office.In case of application over modified bituminous membranes, a period of at least 180 days oxidation is needed.
- Consumption 1.7-1.9 kg/m² in two coats, with ONE MAT interposed.
- Surface Preparation Thoroughly clean the substrate to be treated to remove: dust, crumbly parts, foreign or non-stick substances. Before applying ONE, restore any missing volumes (from 2 to 20 mm), with PRE-ONE, a quick-setting premixed product, also applicable at low temperatures (0 ° C) and in case of humidity. After applying PRE-ONE, wait at least 12 hours before over-applying ONE. For levelling floors with irregularities from 1 to 20 mm, use WINLIVEL RAPID, quick-drying self-leveling. For making a new screed, use WINPLAN 370, a quick-drying screed or WINPLAN PRO, a quick-drying screed with low water absorption.
- Useful Advices The product is ready to use so, DO NOT dilute it with water nor solvents.
- Packaging 1 kg pail 5 - 20 Kg pail
- Colours White-grey-red-terracotta.
- Storage The product in its intact packaging and stored in a dry and protected place has a stability of 12 months. Store at temperatures between + 5°C and + 35°C.
- Stratigraphy ONE - Concrete ONE - Existing flooring ONE - Smooth bituminous membrane ONE and WINJOINT SYSTEM ONE on existing flooring and WINJOINT SYSTEM
- Technical data sheet
BC SEAL PAD
Self-adhesive square pad based on butyl mastic covered with non-woven, which allows the deformation of the product. The adhesive side is protected by peel off support. Use BC SEAL PAD for sealing around roof penetration such as: ventilation pipes, drains, pipe joining and protrusive parts in general. The non-woven conforms to the shape of the surface and can be covered with tile adhesive, liquid or cement waterproofing product, or other coverings.
The product can be used for repairing cracks on cement, fiber cement and metal.
- Use Fields Use BC SEAL PAD for sealing around roof penetration such as: ventilation pipes, drains, pipe joining and protrusive parts in general. The non-woven conforms to the shape of the surface and can be covered with tile adhesive, liquid or cement waterproofing product, or other coverings, in this case it can be applied also in combination with BC SEAL BAND. The product can be used for repairing cracks on cement, fiber cement and metal.
- Application Remove the protection, put the band on the surface avoiding the formation of air bubbles between the butyl and the support. For joints, superimpose the products of at least 5 cm. Apply at a temperature between 0°C and +40°C.
- Surface Preparation Application surfaces must be clean, dry and free from dust, oils, foreign or non-stick substances. On powdery substrates it is advisable to favor the adhesion, a prior application of WINFIX CONCRETE.
- Useful Advices Before applying the product, it is recommended to repair any surface irregularities, paste any detached tiles, and check hidden wet in order to prevent the formation of vapor pressure. Avoid using in imminence of rain or on wet surfaces. The product, once applied, must be covered within 24 hours.
- Packaging Standard length and width: 320 mm
- Colours Non-woven: white Butyl: grey
- Storage The product has 12 months stability from the production date if properly packed and not opened. Store in a ventilated room sheltered from dampness at a temperature between + 5° C and + 35 °C.
- Technical data sheet
WINPLASTER
Formulated by WINKLER’s Research & Development laboratory, WINPLASTER is a product containing additive agents for shrinkage control in both the plastic and hardened stage. The product is used to waterproof skirting at the foot of the plaster (stucco) even on bitumen- polymer membranes and WINKLER waterproofing materials and for levelling and waterproofing concrete or plaster
- Application Mix well, until reaching an even mix consistency. The product can also be used as a rendering coat, just by adding more water (see USAGE); wait for 4 to 5 hours before applying WINPLASTER for single-coating thicknesses of 2 to 3 cm. The product can be applied using a trowel or sprayed.
- Consumption Rendering: 1,5 kg/m2 per mm of thickness.Plaster: 1,6 kg/m2 per mm of thickness.
- Useful Advices CAUTIONSWe recommend applying at temperatures between +5°C and +35°C. Protect from direct sun and wind for the first 24 hours; if necessary continue to moisten the surface after application. Before use store product away from frost and in an environment protected from humid conditions. Mix with clean cold water. Fresh mortar can be removed from tools used with water. After hardening cleaning can be carried out only mechanically. Maximum thickness: 4 cm (reinforced)We recommend using the quantity of water indicated in the technical data table.
- Packaging 25 kg sack.
- Storage The product, in its complete undamaged packaging, remains stable for 12 months. Store at temperatures ranging between +5°C and +35°C in a dry place.
- Stratigraphy WINPLASTER
- Technical data sheet
- Certifications
- Declaration of performance DoP
WIN BITUROOF
Developed by WINKLER’s Research & Development laboratory, WIN BITUROOF is a single component, ready-to-use levelling paste made from water dispersion bitumen. The product guarantees exceptional workability and is easy to apply. It is used for levelling out and restoring slopes on bitumen supports (smooth or slate membranes) before applying a new layer of waterproofing product.
- Application Quickly stir the product to homogenize before use. WIN BITUROOF is ready-to-use and can be applied with a trowel or a smooth metal spatula. Each layer of product should be between 2 to 15 mm. For more application, wait at least 24 hours. Maximum thickness: 4 cm.
- Consumption 1,6 - 1,7 kg/m2 per mm of thickness.
- Useful Advices Clean all substrate surfaces thoroughly in order to eliminate dirt, dust, and loose materials, any form of oil or grease and foreign or bonding-proof matters. Apply only over dry substrates. Modified bitumen membranes must have undergone at least 180 days of oxidation before proceeding with the application of the product.Membranes that are damaged, perforated, feature small humps and depressions or detached, as well as fish-mouth at overlapping seams shall be repaired and sealed using the rubber-bitumen sealing product SHELL TIXOPHALTE.
- Packaging 5 kg pail20 kg pail.
- Storage The product, in its sealed undamaged packaging, remains stable for 12 months. Store at temperatures between +5°C and +35°C.
- Technical data sheet
WINTAPLAST
Two-component thixotropic coloured mortar cured into elastic resistant to U.V. exposure and to positive and negative hydrostatic pressure. After proper application and curing WINTAPLAST is waterproof, permanently elastic and has superior resistance to abrasion while remaining unaffected by adverse weather conditions, frost and salts. WINTAPLAST has obtained the important EC1 PLUS, which identifies EMICODE certified
- Use Fields WINTAPLAST can be used in projects such as: - Repairing and reconditioning concrete structures, including those under large stress. - Waterproofing new and old surfaces subject to heavy pedestrian traffic, both indoors and outdoors. - Waterproof coating for any size fountains, pools, artificial lakes, swimming pools and tanks of non-drinkable water.
- Application Apply WINTAPLAST with metal putty knife, trowel or flat brush. Maximum wet film thickness per coat must be 1.5 mm. Subsequent coat can only be applied after the previous coat is completely dry (10-12 hours at +20°C), but no later than 72 hours. Maximum total thickness of all coats is 3 mm. The surface is walkable after 24 hours from the first coat at +20°C. Avoid mechanical stress for minimum 3 days. Total hardening is reached after 7 days. Do not allow the product to dry too quickly. For this reason, the user shall protect the freshly applied material from direct sun exposure and/or excessive air currents or wind. Apply and cure at temperatures between +5°C and +35°C. To improve the finish appearance, it is recommended to use a sponge trowel before product setting is complete (around 2 hrs at 20°C).
- Consumption 1.8 kg/m2 per mm of thickness.3.5 - 4 kg/m2 for waterproof coating, resistant to abrasion (pedestrian surface), or to de- icing salt.4.5-5 kg/m2 for positive waterproofing (pools, tanks etc.).4.5-5 kg/m2 for negative hydrostatic pressure waterproofing.
- Surface Preparation The substrate must be clean, dry, cohesive, free oil crumbly parts, oils, or other non-stick substances. Irregularities of up to 1.5 mm can be restored with WINTAPLAST. Absorbent substrates such as concrete, plaster, masonry etc. shall be dampened beforehand. Prior to the application of WINTAPLAST it is highly recommended the use of BC SEAL BAND (self-adhesive butyl tape coated with polypropylene non-woven fabric) for proper reinforcement and sealing of corners and penetrations.
- Useful Advices Do not add water to the preparation. Do not add cement or additives. Do not use if packaging is damaged.
- Packaging WINTAPLAST is available in two packaging options:
- 36 kg Package: (Component A 26 kg & Component B 10 kg)
- 18 kg Package: (Component A 13 kg & Component B 5 kg)
- Colours WHITE – CREAM YELLOW (as per RAL 9001) – GREY (as per RAL 7032/7033/7040) – BLUE (as per RAL 5012).
- Storage Product can be stored in a dry and sheltered place at temperatures between +5°C and +35°C for 12 months in its complete and undamaged packaging. Does not tolerate frost.
- Stratigraphy WINTAPLAST containing non-drinking water WINTAPLAST for swimming pools
- Technical data sheet
- Certifications
- Declaration of performance WINTAPLAST DoP
PRE-ONE
Single composite, quick-setting, thixotropic mortar, specially for damp bases and extreme temperatures (from 0° to +45°C). Product with additive agents to control shrinkage in both the plastic and hardened stage, inert agents selected in perfect granulometric curve, formulated in the WINKLER Research & Development laboratories.
- Use Fields Product used to repair patches (up to 2 m2), both horizontally and vertically, of concrete foundations, cementitious screeds, plaster etc. before applying subsequent layers of ONE, ONE VERTICAL or ONE FLOORING.Product with excellent workability that can be applied at thickness from 2 to 20 mm also in a single coat.
- Application Mix well, until reaching an even mix consistency. Apply with a trowel or smooth putty knife. The product can be applied at temperatures from between 0°C and +45°C. For repairs of areas greater than 1m<sup2 (max 2 m2) and for thickness> 1 cm, apply product in 2 coats. With this specific way of putting product into use, any cracking in the product after the first coat, can be repaired with the second coat.File the PRE-ONE surface and remove the dust before the subsequent layer of liquid protection.For overlaying with any type of ONE waterproofing wait at least 12 hours.
- Consumption 1,7 kg/m2 per mm of thickness.
- Surface Preparation Remove the degraded concrete, if necessary carefully sand or wash the surface, which should be free from salt, oil, grease, flaky parts and foreign or non-stick substances, with a pressure washer and water. Wet base thoroughly before application. In the presence of oil stains proceed as described below: remove about 2 mm of the base where oil is present, remove dust and immediately apply ONE PRIMER (primer for oily foundations) with a roller or flat brush, continue immediately to dust with quartz 01-05. Wait at least 24 hours before restoring holes with PRE-ONE.
- Useful Advices Do not add cement or additives.Do not use if sack is damaged.Do not add water when preparation begins to set.Do not apply to tarmac or surfaces treated with bitumen.Do not apply to smooth surfaces.Wait at least 12 hours before any applications on top.
- Packaging Sacks of 15 - 25 kg
- Colours Grey.
- Storage The product, in its complete packaging, remains stable for 12 months. Store at temperatures between +5°C and +35°C.
- Technical data sheet
- Certifications
- Declaration of performance DoP
ONE VERTICAL
Single component coloured fluid applied waterproofing membrane, specifically developed for applications under extreme conditions, such as conditions of thermal shock with temperatures range from 0°C to +45°C, over sloped or vertical substrates containing damp or wet surfaces. ONE VERTICAL is U.V. resistant and provides excellent waterproofing protection to a variety of substrates.
- Use Fields Vertical walls: plaster, concrete, brick, fibre cement, metal and ceramic coatings even those with permanent problems of excess damp.ONE VERTICAL is a fast curing product that tolerates precipitations in a short period of time after its application. The product becomes rain-proofed, although not fully cured, according to the Rain-Proof Time Table provided in the technical sheet.
- Application Mix the product quickly prior to using. ONE VERTICAL is ready for use and does not need primer or protective topcoat. Apply ONE VERTICAL with a metal putty knife (even surfaces), flat brush, short pile roller or airless spray gun (LARIUS – ZEUS, DRAGON or THOR series, please contact our technical support for information). Apply the product in a single coat, covering the substrate completely with no gaps.
- Consumption 350 - 400 g/m² in single coat.
- Surface Preparation Clean all substrate surfaces thoroughly to eliminate dirt, dust, and loose materials, any form of oil or grease and foreign or bonding-proof matter. The substrate shall be sound and cohesive. Any holes (from 2 to 20 mm), shall be repaired with PRE-ONE (fast-setting thixotropic mortar) using a trowel or smooth putty knife. Apply and cure PRE-ONE at temperatures between 0°C and +45°C. Allow to cure least 12 hours. Follow instructions contained in the most recent product’s TDS.
- Useful Advices The product is ready for use and must not be diluted with water or solvent.TOOL & SURFACE CLEANINGClean fresh product with denatured ethyl alcohol. Remove dry product mechanically. For surface cleaning use a solution of water and denatured alcohol in 1:1 ratio.
- Packaging 5 kg pail20 kg pail
- Colours White, light grey, grey, red, terracotta, green.
- Storage Product can be stored in a dry and sheltered place at temperatures between +5°C and +35°C for 12 months in its complete and undamaged packaging.
- Technical data sheet
ONE FLOORING
One-component pigmented liquid applied waterproofing membrane for horizontal surfaces subjected to vehicular traffic or other high-level stress. ONE FLOORING is U.V. resistant providing waterproofing and protection against abrasion, heavy traffic or other mechanical hard-wearing. The product is specially designed to allow its application indoors or outdoors under extreme conditions, such as conditions of thermal shock
- Use Fields ONE FLOORING is particularly recommended for waterproofing and protecting floors/decks subjected to high levels of stress such as: garages or car parking facilities, storage or warehouses, industrial floorings and substrates as concrete, ceramic tiles or other floors/decks with permanent problems of excess dampness, also not completely cured cementitious screeds (7 days at 15°C). Its particular formulation, allows adhesion also over tarmac (with minimum mechanical resistance of 0.5 N/mm2).The product becomes rain-proofed after its application, although not fully cured, according to the Rain-Proof Time Table provided in the technical sheet.
- Application Mix the product quickly before using it. ONE FLOORING is ready for use and does not need primer or protective topcoat. Apply ONE FLOORING with a short-haired roller, smooth trowel or airless spray gun (LARIUS – THOR series), please contact our technical support for information.Apply the first coat by short-haired roller for a consumption of 350-400g/m2. Wait for the time indicated on the temperature table, then apply the second coat, always with roller or metal trowel, for a rate of 1.1/1.2 kg/m2. The use of a spiked roller after the second coat, before it cures, is always recommended.
- Consumption 1.7- 1.9 kg/m2 without reinforcement 1.8 – 1.9 kg/m² with WINTECHNO MAT
- Surface Preparation Clean all substrate surfaces thoroughly to eliminate dirt, dust, and loose materials, any form of oil or grease and foreign or bonding-proof matter.The substrate shall be sound and cohesive with a tear-resistance of at least 1.5 MPa. If oil stains are present on concrete proceed as follow: mechanically remove approximately 2 mm of the substrate surface where oil is present, remove all dust (with vacuum aspirator). Immediately apply ONE PRIMER (two-component epoxy adhesion promoter) with a roller or flat brush and broadcast quartz 01-05 onto the wet primed surface. Allow ONE® PRIMER to cure least 24 hours.
- When repairing any surface up to maximum of 2 m2, apply PRE-ONE (fast-setting thixotropic mortar), using a trowel or smooth putty knife. Apply and cure PRE-ONE® at temperatures between 0°C and +45°C. Follow instructions contained in the most recent product’s TDS.
- If area is larger than 1m2 (max. 2 m2) and/or has more than 1cm in depth we strongly recommend applying PRE-ONE in 2 coats, allowing each coat for proper curing (min. 12 h.) prior to the application of any subsequent layer of material. Any cracks that may appear in the product after the first coat is cured, can be repaired with the second coat. Allow second coat to cure for at least 12 hours.
- When repairing any surface larger than 2 m2 follow the steps below, observing the application and curing temperature range between + 5°C to + 30°C.
- Up to 3 mm thickness: apply UNIBAR FORMULA (multifunctional two component resin) with a roller or flat brush, following instructions in the latest product’s TDS. Allow the product to set for several minutes up to maximum of 24 hours, before resuming to restore the patches with UNIBAR SL (self-levelling tri-composite for screeds, made from epoxy binders and special solvent free fillers (SC2)). Apply ONE® FLOORING after at least 24 hours.
- Over 3 mm thickness: apply UNIBAR FORMULA (multifunctional two component resin) with a roller or flat brush, following instructions in the latest product’s TDS. Allow the product to set for several minutes up to maximum of 24 hours, before resuming to restore the patches with UNIBAR MALTA (synthetic tri-composite mortar made from epoxy binders and special solvent free high resistance fillers (SC1)). Apply ONE FLOORING after at least 24 hours.
- Useful Advices The product is ready for use and must not be diluted with water or solvent.
- Packaging 10 kg pail 20 kg pail
- Colours Light grey, grey, red, green (white and yellow for signage)
- Storage Product can be stored in a dry and sheltered place at temperatures between +5°C and +35°C for 12 months in its complete and undamaged packaging.
- Stratigraphy ONE FLOORING on Concrete ONE FLOORING and WINJOINT SYSTEM
- Technical data sheet
- Certifications
WINPLAN 370
Premixed, fast curing and controlled shrinkage screed, for indoor and outdoor application. Applicable on new or old slabs, underfloor heating pipes, concrete, or existing floors.
- Use Fields Can be applied in balconies, terraces, offices, residential environments, floors subject to high pedestrian traffic such as shopping centres, industrial floors. It can be coated with ceramic, resilient materials, natural stones, parquet, wood or any other coating where rapid drying is required. It is suitable for the creation of radiant floors without adding any additives.
- Application Prepare the level guides for laying with a level staff. Mix WINPLAN 370 (with 2.5 liters of clean water each 25 kg bag), in a glass mixer or a screw mixer, until obtaining a homogeneous and lump-free mix, with a "moist earth" consistency. Lay the mixture, compact it and, for the distribution of loads, with thicknesses from 4 to 8 cm, place a galvanized electro-welded net with 5x5 cm mesh, ø 2 mm, at about half of the thickness. As an alternative, use FIBER HD synthetic fibers (0.5% of the total weight), dispersed in the mixture.
- Consumption 19-20 kg / m² per cm of thickness.
- Useful Advices Do not add cement or additives. Do not use if the bag is damaged. Do not add water when the mixture begins to set. Do not apply on asphalt surfaces or treated with bitumen. Before use, store the product protected from frost and in an environment free from humidity. Mix with fresh and clean water. We recommend applying at temperatures between +5°C and +35°C. Protect it from sun and wind in the first 24 hours from application. Fresh mortar can be removed from the tools used for the preparation and installation with running water. Clean tools mechanically, after hardening.
- Packaging 25 kg bags.
- Storage The product, in its original, unbroken packaging, has a stability of 12 months. Store at temperatures between + 5 ° C and + 35 ° C.
- Technical data sheet
- Certifications
- Declaration of performance WINPLAN 370 DoP
- 1
- 2
